MAG6804 4 Channel Network System Audio Terminal

Features

● Network audio terminal;
● Two network connection ports, can work between different networks;
● Maximum 48KHz sample rate, 16bit digital audio decode;
● 10M/100M10M/100Mautomatic network adaption;
● 24V/100MAoutput and shortcut output;
● Can play background music,emergency paging and alarm signal from the host;
● One EMC input, one EMC output;
● Built-in monitor speaker;

  • Introduction
  • Specification
  • Connection

Network PA system is based on internet and built in modules and layers. It is an integrated and intelligent PA system. The system is digital transmission and realized by Lan. The transmission distance can reach more than 10 kilometers. The configuration of this system can take advantage of the existing LAN system, and is time &cost saving. The combination with the LAN makes it possible for interaction function, which the traditional PA system unable to realize. Unlike traditional PA system which is only able to transmit information in one direction and control in station, this network system make it possible for interaction function due to its combination with LAN system. The network PA system center is able to connect to multiple terminals, such as, play terminal, on-demand terminal, paging terminal, one-touch emergency alarm terminal. The system center has the function of player, zoning, pre-amplifier, timer, equalizer, and powerful audio matrix, etc. The network PA system can be applied to different occasions, such as, airport, port, university, school, large gathering site (e.g. Expo), stadium, industrial park, park, railway, highway, etc.

Test item

Indicator parameters

EMC parameters

(EMC LINE IN port input)

CH1, CH2, CH3 and CH4 rated output

1V

Input sensitivity

MAX:

250mV

MIN:

4V

Effective frequency range of gain limit (±3dB)

50Hz-20kHz

Signal-noise ratio (low pass 30kHz)

≥70dB

Total harmonic distortion (1kHz, 1/3 output voltage)

≤0.1%

EMC LINK output

Equal to EMC LINE input (±10%)

Input dynamic scope

≥26dB

Network decoding parameters (host machine MP3

input)

CH1, CH2, CH3 and CH4 rated output

1V

Distortion degree (1kHz -10dB/MP3)

≤0.2%

Effective frequency range of gain limit

(±3dB):

50Hz-20kHz

Signal-noise ratio (low pass 30kHz)

≥70dB

Alarm output

(Host software

control)

COM-24V output

24V (≤100mA)

COM-SC output

Short circuit (<1Ω)

Built-in monitoring power

1.2W

Network

Dual network interface 10M/100M self-adaptive

Power

AC 180V-242V/50Hz

Power consumption

12W
