D6609 MAG6363G DSP2020A/B_Teaching Microphone Used in Classroom

D6609-MAG6363G-DSP2020A/B


_Teaching Microphone Used in Classroom


Solution Overview



How Do I Choose the Right Audio Solution?
An effective system evenly distributes all classroom audio sources so every student hears equally well.
Here's how to determine your specific classroom needs.



▄  Small Classroom Application

1.1. Small Classroom Requirements

Even small rooms with few students can be too noisy for students to hear clearly, and the younger they are the more help they need.



Project Requirements
Size: 400-600 ft2
● Number of students: <10
● A teacher holds a microphone and can connect to Bluetooth to play background music.
● The sound reinforcement system needs to provide clear and pure sound quality so that students and teachers can listen easily and improve the quality of teaching.
● Classroom sound reinforcement systems need to be easy to manage, easy to use, anti-interference, and convenient for school management and maintenance.

1.2. Product_Wireless Teaching Audio Loudspeaker(DSP6609)



Features
● 2.4G wireless teaching audio loudspeaker with microphone
● Built-in 4x10W/@4Q digital amplifier, high efficiency
● Built-in 2.75"x4 full frequency driver unit ,Support max 99 channels
● Priority: Mic>Bluetooth>AUX
● Pairing type 2.4G, transmission type UHF ,With DSP technology, better sound effect
● Support blue-tooth for wireless transmission
● Support Infrared remote controller, easy to operate
● Working time of microphone is around 4 hours
● The wireless microphone is powered by one AAA battery, easy to carry
● The same microphone could be used in different classroom with no crosstalk
● Speaker pendant bracket distance could be adjusted from 18cm to 33cm

1.3. Product_Wireless Microphone(DSP6626C)




1.4. Function Highlights



1.5. Installation Diagram



▄  Regular Classroom  Application

2.1. Medium-sized Regular Classroom Requirements

Medium-sized regular classrooms can have a network PA system installed to realize the combination of school ringing and local sound reinforcement.



Project Requirements
● Size: 600-800 ft2
● Number of students: 11-32
● A teacher holds a microphone and can connect to Bluetooth to play background music.
● The sound reinforcement system needs to provide clear and pure sound quality so that students and teachers can listen easily and improve the quality of teaching.
● Classroom sound reinforcement systems need to be easy to manage, easy to use, anti-interference, and convenient for school management and maintenance.

2.2. MAG6363G 2.4G Wireless Teaching System _with Network PA System



● Using 2.4G transmission mode, it can be used for local sound reinforcement and multimedia teaching of "one teacher holds one microphone"; it can also be connected to Bluetooth to play background music.
● The microphone has a built-in true reverberation function, which effectively improves the sound quality of speech, making it less dry or harsh, and the reverberation level is adjustable.
● The microphone supports PPT page turning: The PPT page turning module supports hot swapping and does not require driver software.

2.3. MAG6363M UHF Wireless Teaching System_with Network PA System



● Using UHF transmission mode, it can be used for local sound reinforcement and multimedia teaching; it can also be connected to Bluetooth to play background music.
● It uses a built-in electret pickup and designs an independent pickup cavity, which can effectively suppress howling and increase the pickup distance. The cavity has built-in acoustic sponge pads to minimize noise.
●  The device has a pen-shaped body design, which is comfortable to hold and ergonomic. The buttons are partitioned and designed for easy operation. The appearance is fashionable, novel and beautiful, and the entire microphone (including the built-in microphone) weighs less than 40 grams, which is light and easy to hold.
●  The microphone supports PPT page turning: The PPT page turning module supports hot swapping and does not require driver software.

2.4. MAG6420II UHF Wireless Teaching System_with Network PA System



● Wall Mount Network  Wireless Microphone Control Panel (MAG6420II-C), uses RJ45 connection interface, supports 485 transmission protocol, and the maximum transmission distance is up to 300 meters.
● In irregular areas, it can be installed on the nearest wall to ensure signal stability. The receiving microphone stably transmits audio data within an open area 15 meters away from the "Control Panel (MAG6420II-C)".
● Using UHF transmission mode, it can be used for local sound reinforcement and multimedia teaching; it can also be connected to Bluetooth to play background music.

▄  Large Classroom  Application

3.1. Large Classroom Requirements

The main demand for sound reinforcement in large classrooms is to ensure that the sound covers the entire classroom clearly and evenly, so that every student can hear the teacher's explanation clearly, and improve the quality and efficiency of teaching.



Project Requirements
● Size: 800-1000 ft2
● Number of students: 32+
● A teacher holds a microphone and can connect to Bluetooth to play background music.
● The sound reinforcement system needs to provide clear and pure sound quality so that students and teachers can listen easily and improve the quality of teaching.
● Classroom sound reinforcement systems need to be easy to manage, easy to use, anti-interference, and convenient for school management and maintenance.

3.2.  Large Classroom--Teaching Audio System_Product Configuration



No.

Model

Product Name

Quantity

1

DSP2020A

UHF TeachingMicrophone System

1PC

2

MP120UB

Mixer Amplifier

1PC

3

DSP5020

20W wall mount speaker

4PCS



3.3. Function Highlights



Customized Style
● The system host can support simultaneous use with two handheld microphones.
● Two pairing types: UHF and Infrared, rapid pairing, stabile and no distraction。
● The system host has two built-in frequency binding modules, and the sound is mixed and output when two handheld microphones are used at the same time.
● When setting different channels, the same microphone can be used in different classrooms without interfering with each other.



Design Highlights
● It adopts high-performance audio processing chip and ultra-low distortion sound processing circuit design.
● The advanced digital pilot technology and independent ID code design are adopted to prevent cross-frequency.
● Built-in feedback suppressor can effectively suppress howling and noise.
● The ultra-high frequency dynamic compression shunt technology automatically loads the high and low frequencies to show the best performance.

3.4. PPT Page Turning Function



Laser Pointer with Remote Control
● Supports PPT page turning function and one-click black screen/recovery function.
● Supports hot swapping, no need to install driver software.
● Plug and play (the handheld microphone needs to be paired with the receiving module first, and then the USB page turner is plugged in).
● Using a standard Class 3B laser module, the red laser spot is larger and brighter to clearly highlight the key points of the speech.
● Can be used with a projector or computer for presentation and explanation.

3.5. Product Features



Features
● Two pairing type: UHF and Infrared, rapid pairing
● Working distance longer than 30 meters
● ith volume control and mute function
● Support handhold Mic, Headset Mic and wireless clip mic
● The handhold Mic support teaching laser pointer
● Support PPT page turning and one key black screen/restore function
● With 3.5mm jack for audio input or headset mic input
● Built-in feedback suppressor, no noise and squeaking
● The same microphone could be used in different classroom with no crosstalk
● Energy efficiencyautomatic shutdown after 60 minutes without signal input
● The microphone built-in 120mA lithium battery, charge time 2 hours, working time more than 7 hours

4. Product Features Comparison



No.

Specification

Parameters

1

Model

DSP6609

MAG6363G/M

DSP2020A/B

2

Transmission Mode

2.4G

2.4G/UHF

UHF

3

MIC Automatic Frequency Pairing Distance

within 0-3 meters

within 0-4 meters

within 0-2 meters

4

MIC Signal Distance

30 meters

30 meters

30 meters

5

Bluetooth Receiving Distance

10 meters

10 meters

No Bluetooth

6

PPT Page Tuner

No

Standard Configuration

Optional Configuration
