DSP3012A 300W Outdoor Horn Speaker System

Features

● Outdoor design, suited for both outdoor and indoor use
● Max SPL: 132±2dB( 1m )
● Built-in 100v/70v transformer
● Wide Freq.Resp.:70Hz-18kHz
● High sensitivity: 108dB
● Dispersion 40°×60°
● With mounting holes for three-point installation

  • Introduction
  • Specification
  • Connection

The DSP3012A is an outdoor speaker with a 70v/100v transformer built in. The 70v/100v transmission is realized in a high-voltage, low-current mode, which makes longer distance transmission and parallel connection of multiple loudspeakers possible.

This speaker is designed of wide frequency response (70Hz-18kHz); It is of high quality and can ensure long-term durability, and will never be out of shape; Equipped with bracket for hanging from three point; Driver surround excellent damping, long life, clear and sonorous sounds.

It can be applied to different occasions vary in area sizes and background noises, such as station, park, school, square, military camp, industrial park, etc.


Model

DSP3012A

RatedPower

300W

Line Voltage

70/100V

Sensitivity(1M,1W)

108dB

Max SPL(1M)

132±2dB( 1m )

Freq. Resp

70Hz-18kHz

Dispersion(H*V)

 40°×60°

Weight

45kg
