PC1008RII AM/FM Audio Tuner

Features:

● Microcomputer control, digital tuning system.
● Touch button control, VFD display operation status.
● 40 radio stations for storage in AM band and FM band respectively, and the stored radio stations can be recalled at any time.
● With auto radio stations searching and storage.
● With audio signal level indicator.
● With permanent power-off memory.
● Support PC remote control.
  • Introduction
  • Specification
  • Connection

Receiving Range

FM

87.0-108.0MHz


AM

522-1620kHz

Sensitivity

FM

4dBμ


AM

35dBμ

SNR

FM

>60dB


AM

>70dB

Tuning Frequency Step

FM

1kHz


AM

1kHz

IF Frequency

FM

10.7 MHz


AM

450 kHz

Maximum Output Level

1.8dBV

Protection

AC fuse

Power

AC220V/50Hz

Package Dimensions (mm)

(L×W×H) 555×455×185

Machine Dimensions (mm)

(L×W×H) 484×320×88

Gross Weight

7.5kg

Net Weight

5.7kg
