MP6935 350W 6 Mic Conference Amplifier

Name: MP6935 350W 6 Mic Conference Amplifier
Brand: Guangzhou DSPPA Audio Co., Ltd.

Features

● Efficient and reliable operation with integrated functionality.
● 4 LINE IN, 1 LINE OUT, 6 MIC IN (Balanced, ungrounded, with 24 V phantom power).
● Automatic detection of input status for 4 audio channels on power-up, prioritizing higher-priority signals.
● Priority sequence: AUX1, AUX2, AUX3, AUX4.
● Mute function for easy interruption of normal playback.
● DSP frequency shift processing for microphones with frequency shift capability.
● Built-in chime generator with adjustable volume.
● Independent volume control for microphones and audio channels, with master volume control for amplifier output.
● 7-band EQ for easy adjustment, with EQ/Bypass option.
● 100V and 70V rated voltage output, designated as P1 output.

Contact now Leave message

Introduction
Specification
Connection

This Mixing amplifier is 70V,100V&16Ω and rated at 350W. It has 4 line inputs, 1 line output, and 6 microphone inputs. 4 audio source channels can be selected automatically. With mute function, easy to override the normal playing. With built-in chime generator, and the chime output volume is adjustable. This product is professional audio mixer.

Model	MP6906	MP6912	MP6935
Rated Output Power	60W	120W	350W
Output Voltage Regulation	From full load to no load, ≤3dB
MIN. EMF.	MIC: ≤3mV (Unbalanced input)
	MIC: ≤3mV (Balanced input)
	LINE: ≤300mV
Frequency Response	80Hz -16KHz (±3dB)
THD	≤0.5 (1KHz, under normal working condition)
SNR	LINE: ≥70dB
7-band EQ	64HZ: ±12dB
	160HZ: ±12dB
	400HZ: ±12dB
	1KHZ: ±12dB
	2.5KHZ: ±12dB
	6.4KHZ: ±12dB
	15KHz: ±12dB
Protection Function	DC, overload, short circuit.
Mute Function	MIC1 and chime input override other inputs.
Phantom Power	DC24V
Frequency Shift	0-5Hz higher than the input signal frequency
Working Power	AC220V/50Hz
Rated Power Consumption	120W	250W	650W
Package Dimensions (mm)	(L×W×H) 555×455×185
Machine Dimensions (mm)	(L×W×H) 430×368×88
Gross Weight	12kg	13.8kg	17.8kg
Net Weight	10.2kg	12kg	16kg
