The 100V network amplifier MAG6895 is a kind of network fully digital analog-to-digital signal processor based on 100/10Mbps self-adaptive TCP/IP network transmission protocol; with the design of dual network backup, it is allowed to access to any switch simultaneously. Also, the device features network line fault detection and automatic selection for improved reliability.
The device can output remote audio data streams as audio signals, which is intelligently controlled by the host. The device has a built-in MP3 player, a USB interface and an SD card slot, which allows you to play MP3 programs on the device without playing network audio stream signals. It is provided with an auxiliary audio input interface for connecting other audio source equipment (e.g. DVD), and an auxiliary audio output interface for connecting other amplifiers to expand the power, as well as a microphone interface for local paging.
|
Model |
MAG6895 |
|
|
Model |
MAG6895 |
|
|
AUX IN |
Input Sensitivity |
350mV±50mV |
|
Frequency Response |
80Hz-15kHz(±3dB) |
|
|
Distortion |
≤1 % |
|
|
SNR |
≥77dB |
|
|
AUX OUT |
Rated Output |
1000mV±100mV |
|
Frequency Response |
80Hz-15kHz(±3dB) |
|
|
Distortion |
≤1 % |
|
|
SNR |
≥75dB |
|
|
MIC IN |
Input Sensitivity |
5mV±1mV |
|
Frequency Response |
80Hz-15kHz(±3dB) |
|
|
Distortion |
≤1 % |
|
|
SNR |
≥71dB |
|
|
USB/SD/NET MP3 Playback |
Frequency Response |
80Hz-15kHz(±3dB) |
|
Distortion |
≤1 % |
|
|
SNR |
≥77 dB |
|
|
100V Constant Voltage Output |
Rated Output Power |
1000W |
|
Frequency Response |
80Hz-15kHz(±3dB) |
|
|
Distortion |
≤1 % |
|
|
SNR |
≥77dB |
|
|
Supported SD Card Capacity |
32GB |
|
|
Supported USB Flash Disk Capacity |
32GB |
|
|
Rated Consumption Power |
1300W |
|
|
Power Supply |
AC220V/50Hz |
|
|
Over Current, Overheat, Over Voltage Protection |
Satisfied |
|
|
Display Screen |
Digital Screen |
|
|
Gross Weight |
7.77kg |
|
|
Net Weight |
6.12kg |
|
|
Package Dimensions (L×W×H mm) |
525×490×105 |
|
|
Machine Dimensions (L×W×H mm) |
483×400×44 |
|
