MAG6895 Network Amplifier (1U)

Features

● IP network amplifier
● 100V speaker output
● Rated power 1000W
● Digital amplifier
● Audio source: AUX,Mic,USB,SD
● Digital screen to indicate running status
● One AUX input, one Mic input, one AUX output & EMC output

  • Introduction
  • Specification

The 100V network amplifier MAG6895 is a kind of network fully digital analog-to-digital signal processor based on 100/10Mbps self-adaptive TCP/IP network transmission protocol; with the design of dual network backup, it is allowed to access to any switch simultaneously. Also, the device features network line fault detection and automatic selection for improved reliability.

The device can output remote audio data streams as audio signals, which is intelligently controlled by the host. The device has a built-in MP3 player, a USB interface and an SD card slot, which allows you to play MP3 programs on the device without playing network audio stream signals. It is provided with an auxiliary audio input interface for connecting other audio source equipment (e.g. DVD), and an auxiliary audio output interface for connecting other amplifiers to expand the power, as well as a microphone interface for local paging.

Model

MAG6895

Model

MAG6895

AUX IN

Input Sensitivity

350mV±50mV

Frequency Response

80Hz-15kHz(±3dB)

Distortion

≤1 %

SNR

≥77dB

AUX OUT

Rated Output

1000mV±100mV

Frequency Response

80Hz-15kHz(±3dB)

Distortion

≤1 %

SNR

≥75dB

MIC IN

Input Sensitivity

5mV±1mV

Frequency Response

80Hz-15kHz(±3dB)

Distortion

≤1 %

SNR

≥71dB

USB/SD/NET MP3 Playback

Frequency Response

80Hz-15kHz(±3dB)

Distortion

≤1 %

SNR

≥77 dB

100V Constant Voltage Output

Rated Output Power

1000W

Frequency Response

80Hz-15kHz(±3dB)

Distortion

≤1 %

SNR

≥77dB

Supported SD Card Capacity

32GB

Supported USB Flash Disk Capacity

32GB

Rated Consumption Power

1300W

Power Supply

AC220V/50Hz

Over Current, Overheat, Over Voltage Protection

Satisfied

Display Screen

Digital Screen

Gross Weight

7.77kg

Net Weight

6.12kg

Package Dimensions (L×W×H mm)

525×490×105

Machine Dimensions (L×W×H mm)

483×400×44
