DSP9030 30W IP66 Waterproof Outdoor Wall Mount Speaker

Features

● An 8Ω constant-resistance speaker.
● Made of ABS material.
● With IP66 waterproof level.
● Exclusive OBE Technology: Optimal Bass Enhancement Radiator, a state-of-the-art bass radiator design, using Anacord’s Exclusive Optimal BASS Enhancement (OBE) Technology that will deliver an outstanding deep and clear bass audio experience even without any extra subwoofer support.

  • Introduction
  • Specification

This product is an 8Ω wall-mounted speaker, which is made of ABS material and features IP66 waterproof level. Additionally, it is provided with power taps to address different requirements, and designed with exclusive OBE technology for optimal bass enhancement.

Model

DSP9030

DSP9040

DSP9050

Tweeter

0.75” (20mm) aluminum dome

0.75” (20mm) aluminum dome

0.75” (20mm) aluminum dome

Woofer

5” (125mm) PP cone, rubber surround

6.5” (165mm) PP cone, rubber surround

8” (203mm) PP cone, rubber surround

Frequency Range ±3

98Hz-20kHz

95Hz-20kHz

45Hz-20kHz

Power Handing RMS

60W program, 30W (IEEE 219)

80W program, 40W (IEEE 219)

100W program, 50W (IEEE 219)

Sensitivity

86dB

87dB

86dB

Impedance

Taps

8Ω, 100V/30W, 15W, 7.5W, 3.75W

8Ω, 100V/40W, 20W, 10W, 5W

8Ω, 100V/50W, 25W, 12.5W, 6.25W

Termination

Standard pressed connector

Standard pressed connector

Standard pressed connector

Dimensions (H*W*D)

275×170×168mm

285×200×195mm

380×249.5×280mm

Certifications

IP66 waterproof speaker

IP66 waterproof speaker

IP66 waterproof speaker

Housing Material

ABS

ABS

ABS
