D4516 460W All-Weather Professional Column Speakers

Features

● Rated power: 460W (8Ω) Driver units: 5.5 inches x 4 + 1 inch x 16 Frequency Response @ -6dB: 100Hz - 20KHz Constructed with birch plywood, featuring an environmentally friendly water-based paint surface Crafted with a box body made from high-strength multi-layer birch plywood Designed with a durable black surface treated using wear-resistant sprinkle spraying Equipped with a dust-proof steel protective iron mesh to ensure protection from dust and other environmental factors

  • Introduction
  • Specification

D4516 waterproof professional column speaker is a versatile audio device designed to enhance speech clarity and sound field effects in various fixed installation places, including outdoor performances, conference rooms, stadiums, and banquet halls. Made of high-strength birch plywood, the speaker features a waterproof treatment and wear-resistant black surface, ensuring durability and longevity. Additionally, the device uses environmentally friendly water-based paint and optimized SPL to improve the ratio of direct sound to reflected sound, resulting in reduced vertical radiation lobe width for optimal vocal and musical processing.

Model

D4508

D4516

Rated Power

230W

460W

Suggested Amplifier Power

300W

600W

Instantaneous Power IEC 268-5

300W

600W

Impedance

Frequency Response@-6dB

100Hz - 20KHz

100Hz - 20KHz

Full Range Unit

2 x 5.5" - 1" Voice Coil/Ferrite

4 x 5.5" - 1" Voice Coil/Ferrite

Treble Unit

8 x 1" - 0.75" Voice Coil / Neodymium Magnet

16 x 1" - 0.75"Voice Coil / Neodymium Magnet

Sensitivity @1W/1m

95dB

98dB

Max./ Peak Sound Pressure

120dB / 123dB

126dB / 129dB

Diffusion Angle H×V

150°x 40°

150°x 20°

Suggested High-pass Filtering

100Hz/24dB  Frequency Doubling

100Hz/24dB Frequency Doubling

Input Connection

2x Euroblock

2 x Euroblock

Dimension (W×H×D)

160mmx360mmx180mm

160mmx600mmx180mm

Net Weight

4.55kg

9.14kg
