D6108 2K HD Seamless 8 Channel Hybrid Matrix

Features

● Support 8-channel signal inputs and outputs
● Matrix system for audio and video signal switching
● Support HDMI, DVI, VGA, SDI, and AV seamless input/output signal cards
● Support multiple signal input and output cross-matrix switching
● Power-off protection, power-off memory, audio and video synchronization or separate switching
● With RS232 communication and TCP/IP control

  • Introduction
  • Specification

The product is equipped with such functions such as power-off protection, audio and video synchronization and separate switching, and has RS232 communication port and TCP/IP (optional) control, which can be matched with the personal computer, remote system or different kinds of remote control devices easily. It has an extensive application in the radio and television engineering, multimedia conference hall, large screen display engineering, television teaching and command control center.

Model

D6108

D6116

D6132

Output

HDMI

Sensitivity

500±50mV

Max. voltage

2.2±0.2V

Freq. Resp.

50-20kHz (±3dB)

Distortion

≦0.5%

SNR

≧76dB

Crosstalk attenuation

≦-80dB

VGA

Sensitivity

1000±100mV

Max. voltage

2±0.2V

Freq. Resp.

20-20kHz (±3dB)

Distortion

≦0.5%

Crosstalk attenuation

≦-68dB

SNR

≧80dB

DVI

Signal strength

T.M.D.S+/-0.4Vpp

Min.\Max. level

T.M.D.S2.9V/3.3V

InputEDID

System defaultEDID

Impedance

50Ω

Max. direct offset error

15mv

SDI

Sensitivity

500±50mV

Max. voltage

2.2±0.2V

Freq. Resp.

50-20kHz (±3dB)

Distortion

≦0.5%

SNR

≧76dB

Crosstalk attenuation

≦-80dB

AV

Sensitivity

1±0.1V

Max. voltage

2.2±0.2V

Freq. Resp.

20-20kHz (±3dB)

Distortion

≦0.5%

SNR

≧80dB

Crosstalk attenuation

≦-68dB

HDMI

Max. voltage

2.2±0.2V

Freq. Resp.

50-20KHz (±3dB)

THD

<0.3%

SNR

>70dB

Crosstalk attenuation

≦-80dB

Noise floor

<0.5mV

VGA

Max. voltage

2.2±0.2V

Freq. Resp.

20-20KHz (±3dB)

THD

≦0.3%

SNR

≧80dB

Crosstalk attenuation

≦-68dB

Noise floor

≦0.5mV

DVI

Interface type

DVI-Dfemale interface

Min.\Max. level

T.M.D.S.2.9V/3.3V

Impedance

50Ω

SDI

Max. voltage

2.2±0.2V

Freq. Resp.

50-20KHz (±3dB)

THD

<0.3%

SNR

>70dB

Crosstalk attenuation

≦-80dB

Noise floor

<0.5mV

AV

Max. voltage

2.2±0.2V

Freq. Resp.

20-20KHz (±3dB)

THD

<0.3%

SNR

>80dB

Crosstalk attenuation

≦68dB

Noise floor

<0.5mV

Screen size

4.3ʺ

Packing size

530×485×190mm

530×485×250mm

530×485×355mm

Machine size

483×330×88 mm

483×330×132 mm

483×330×220mm

Gross weight

7.7kg

9.5kg

13.8kg

Net weight

6.7kg

8.5kg

12.3kg
