The D6233 and D6234 are dedicated discussion units designed for seamless integration into digital conference environments. Featuring recessed in-table mounting and a quick-release cardioid gooseneck microphone, they deliver clear acoustic pickup and user-friendly operation. When networked with the central system controller, these units facilitate automated PTZ camera tracking and comprehensive session control. Powered directly over the main system bus, they offer long-term operational stability for professional boardrooms and council chambers.
Model | D6233 D6234 | |
Structure Type | Embedded | |
Effective Frequency Range with Gain Limit (±3dB) | Unit A to Unit B Monitoring | 80Hz–8kHz |
Host Line to Unit Monitoring | 60Hz–10kHz | |
Unit to Host Line Output | 80Hz–10kHz | |
Static Power Consumption | <1W | |
Maximum Power Consumption | 2W | |
Signal-to-Noise Ratio | >80dB | |
Crosstalk Attenuation | >80dB | |
Harmonic Distortion | <0.5% | |
Headphone Output | 9dBu, 8–32Ω, 3.5mm | |
Operating Power | DC24V supplied by host | |
Unit Interface | RJ45 | |
Microphone | Microphone Type | Cardioid electret condenser |
Input Sensitivity | -45 ±2 dBV/Pa | |
Frequency Response | 50Hz–16kHz | |
Maximum SPL | 115dB | |
Overall Dimensions (W × D × H) | 140 × 63 × 75 mm | |
Panel Dimensions (W × D × H) | 140 × 63 × 6 mm | |
Chassis Dimensions | 130 × 45 mm | |
Package Dimensions | 510 × 210 × 165 mm | |
Net Weight | 1 kg | |
Gross Weight | 2 kg | |
