D6575 Digital Audio Processor
Features:
● Fully digital audio signal processing, automatic, intelligent, specially designed for conference and high-end venues
● 96KHz sampling frequency, 32-bit DSP processor, 24-bit A / D and D / A conversion
● 2 RCA audio inputs, 5 Mic inputs of 3 groups, 3.1 and 5.1 channel audio output optional
● With USB and RJ-45 interface to link with computer, can set up the system via PC software
● With 9 band equalizer adjustment and delay for music input and mic input, can set up in the panel or via PS software
● With 7 band equalizer adjustment and delay for each output, can set up in the panel or via PS software
● With low-cut and high-cut frequency filter for music input and mic input
● 1 U slim design, suitable for 19" rack mounting
- Introduction
- Specification
- Connection
Model
|
D6575
|
Input channel
|
7
|
Output
channel
|
5.1/3.1
|
Input impedance
|
20kΩ/balanced
|
Output
impedance
|
100Ω/balanced
|
Freq.response
|
20Hz-20kHz(-0.5dB)
|
Power supply
|
AC 220V/110V,
50/60Hz
|
Dimension
|
482´ 230´ 44mm
|
Weight
|
4.5kg
|
