DSP203N IP Network Column Speaker

Features

● 10/100M adaptive, support DHCP/static IP settings.
● Support standard SIP protocol.
● Support protocols: DHCP, UDP, ICMP, IGMP (multicast).
● Use primary color seaweed salvaged pulp drum paper and full-range double-cone speaker for wider frequency response, and clear, bright and authentic sound.
● The speaker box is made of high-quality fiberboard and birch cold-pressed veneer to effectively prevent resonant sound.
● Designed with main and sub speakers.
● Equipped with mounting bracket, easy to install.
● DSP203N RMS 2×15W, DSP403N RMS 2×30W.
● With 1 LINE IN and 1 LINE OUT.

  • Introduction
  • Specification

This product is a network column speaker. It is made of high-quality birch, and the speaker unit adopts primary color seaweed salvaged pulp drum paper and full-range double-cone speaker for wider frequency response. It is equipped with mounting bracket for easy installation.




Items

Specifications

DSP203N

DSP403N

Acoustic System

Speaker Unit

4”×2

4”×4

Sensitivity (1m, 1W)

90±2dB

94±2dB

MAX. SPL. (1m)

99±2dB

108±2dB

Frequency Response

200Hz-10KHz

200Hz-10KHz

Amplifier System

Amplifier

Rated Power (RMS)

2×15W/4Ω

2×30W/8Ω

Frequency Response

80Hz-18KHz

80Hz-18KHz

S/N Ratio

≥71dB

≥71dB

Distortion

≤1%

≤1%

LINE IN

Input Impedance

>10kΩ

>10kΩ

Input Sensitivity

1000mV

1000mV

LINE OUT

Output Sensitivity

1000mV

1000mV

Others

Network Interface

RJ45 (10/100M)

Audio Priority

Fire Alarm>Paging>Camera Trigger>Chime>Timing>Net Audio=Audio Collector>AUX IN

Power Input

~100-240V 50Hz/60Hz 1A

Dimensions (H×W×D)

390×138×120mm

682×138×120mm

Weight

3.0kg

5.0kg
