DSP405N Network Waterproof Column Speaker

Features

● Full-range frequency speaker, clear bass and treble.
● 10 / 100M adaptive, support DHCP / static IP, support LAN and WAN.
● It is able to operate independently from the network and the host.
● The design is overall waterproof with the IP55 test. Aluminum alloy box, it is not easy to have deformation and rust.

  • Introduction
  • Specification
  • Connection

DSP405N is waterproof with built-in memory, especially produced for DSP9000 Network Audio System, which is easy to set up (no need of IP address setting), easy to use (plug and play), more reliable (support online and offline running). The system includes all kinds of IP terminals like IP Network Server, IP Paging Microphone, IP Speaker, IP Audio Terminal, IP amplifier, IP Fire Alarm Panel, etc. It offers a new IP audio solution to medium to large audio projects such as hotel, supermarket, shopping mall, rest home, school, etc.

Item

Specification

DSP205N

DSP405N

Acoustic system

Speaker unit

4"×2,2.5"×1

4"×4,2.5"×1

Sensitivity(1m,1W)

89±2dB

93±2dB

SPL(1m)

102±2dB

109±2dB

Frequency response

140Hz-14KHz

140Hz-14KHz


Rated power(RMS)

30W

60W

Amp system

Amplifier

Frequency response

20Hz-20KHz

20Hz-20KHz

S/N ratio

≥81dB

≥81dB

Distortion

≤0.1%

≤0.1%

Audio

Decoding format

MP3,WAV,ACC,M4A,APE,FLAC, etc.

Others

Network interface

R J45 (10/100M)

Support protocol

DHCP, TCP/IP, UDP, ICMP, IGMP (Multicast),

802.1x, HTTP, HTTPS, FTP, DNS, DDNS,

RFC3261, RTP, RTSP, RTCP, UPnP.

Power supply

~90-240V

Dimension(H×W×D)

400×160×120mm

657×160×120mm

Weight

5.5kg

6.2kg


DSP405N Network Waterproof Column Speaker
