DSP405N Network Waterproof Column Speaker

Features

● 10/100M self-adaptive, support DHCP/static IP.
● Support standard SIP protocol.
● Support audio formats: MP3, WAV, etc.
● Can play BGM, emergency paging and alarm signals from the host system.
● Full-range speaker, with clear bass level and bright treble.
● Overall waterproof, with the IP65 certificate.
● Unit driver: Waterproof primary color FB basin, 3-inch magnetic circuit.
● Front panel: Polymer hot injection molding, waterproof and mildew proof.
● Case: Solid aluminum alloy, not easy to deform and rust.
● Aluminum mesh: Made of aluminum, UV coating on the surface for long term use in the outdoors.
● Mounting bracket: Stainless steel bracket, to effectively guarantee the safety after installation.

  • Introduction
  • Specification
  • Connection

This product is a network waterproof column speaker, with clear bass and bright treble. The unit driver is made of waterproof primary color FB basin and 3-inch magnetic circuit, and the mesh is made of aluminum, with UC coating on the surface for outdoor applications. It offers a new IP audio solution to medium to large audio projects such as hotel, supermarket, shopping mall, rest home, school, etc.

Model

DSP205N

DSP405N

Acoustic System

Unit Driver

4” ×2, 2.5”×1

4”×4, 2.5”×1

Sensitivity (1m, 1W)

89±2dB

93±2dB

MAX. SPL. (1m)

102±2dB

109±2dB

Frequency Response

140Hz-14KHz

140Hz-14KHz

Amplifier System

Amplifier

Rated Power (RMS)

30W

60W

Frequency Response

20Hz-20KHz

20Hz-20KHz

SNR

≥81dB

≥81dB

Distortion

≤0.1%

≤0.1%

Others

Network Interface

RJ45 (10/100M)

Supported Protocols

DHCP, UDP, ICMP, IGMP (multicast)

Power Input

~100-240V 50Hz/60Hz

Product Size (H×W×D)

400×160×120mm

657×160×120mm

Weight

5.5kg

6.2kg



DSP405N Network Waterproof Column Speaker
