MA2250U 2*250W Multimedia Mosque Amplifier

Features

● 70V/100V & 4-16Ω speaker output
● Rated power: 2*250W
● Separate 2 channels output control of Volume/Echo/Bass/Treble
● Built-in 3 Mic and 1 AUX and USB/Bluetooth, 1 Chimes, 1 AUX output
● Combo for Mic1,XLR for Mic2 - Mic3, with phantom power 48V
● Individual volume control for Mic1-3 and Aux input
● Priority: Chime=MIC1-3>AUX/Bluetooth/USB
● Protection: Overload, Clipping, Short circuit and temperature protection
● With 19" rack mount handles
● Power supply: AC220V-230V/50/60Hz

  • Introduction
  • Specification

MA2250U is a 2-Channel multimedia mosque mixer amplifier with RMS power 2*250W. Separate 2 channels output control of Echo/Bass/Treble/ Volume and built-in 3 Mic and 1 AUX and USB/Bluetooth. It is suitable for mosques supermarkets, meeting rooms, training rooms and other places.



Model

MA2250U

Rated Power

2×250W

Output Interface

Barrier Terminal Block

AUX Input Sensitivity

350MV

MIC Input Sensitivity

20kΩ/Balanced, 10kΩ/ unbalanced

SNR

≥75dB

Tone Adjustment

Bass:±10dBTreble:±10dB

Frequency Response

45Hz-20kHz(±1dB)

Distortion

<0.1%@1KHz

Power Supply

AC220-240V/50Hz

Protection

Load short circuit, DC output, power on/off, over temperature

Power Consumption

700W

Machine Size

(L×W×H)484×412×90mm

Package Size

(L×W×H)535×470×165mm

Net Weight

16.0kg

Gross Weight

16.8kg
