MAG2406/MAG2412/MAG2425/MAG2435 Network Broadcasting Amplifier Without Latency

Features

● Dante network power amplifier
● Dual Network interface design, support hand-in hand link
● Dual channel with individual volume & tone control
● 70V/100V/200V speaker output with alternation switch
● Audio input for each channel output with alternation switch
● Built-in short-circuit EMC input for each channel
● With forced insertion for volume controller connection
● With individual 4 LED status indicators for each channel
● Protection from overheat,overload,clip & short circuit
● Power supply:AC220V/50Hz

  • Introduction
  • Specification

The MAG2406/MAG2412/MAG2425/MAG2435 device is a public address amplifier with dual channels, with adjustable independent volume and tone for each channel. It is equipped with an overridden control input port (effective for short circuit); three-wire output for easy wiring; dual network interface design for hand-in-hand connection; it can transmit audio signals input by the two-channel audio acquisition input module through the network to the local machine.

Specification

MAG2406

MAG2412

MAG2425

MAG2435

Rated Output Power

60W

120W

250W

350W

MIN. EMF.

≤1000mV

SNR

≥85dB (Aweighting)

Output VoltageAdjustmentRate

From full load to no load, ≤3dB

Frequency Response

100Hz~20KHz (±3dB)

Tone

100Hz(±12dB)


10kHz

(±12dB)



THD

<0.3%

(1KHz, under normal working condition)



Indicator

“POWER”,“CLIP”,“SIGNAL”,“PROTECTION”,“NO LOAD”

Protection

Overheating, DC, short circuit.

Power Supply

AC220V/50Hz

Rated Power Consumption

200W

400W

800W

1100W

Package Dimensions(mm)

(L×W×H) 535×525×195

Machine Dimensions(mm)

(L×W×H) 484×443×88

Gross Weight

18.1kg

20.5kg

24.6kg

26.7kg

Net Weight

15.6kg

18kg

22kg

24.2kg
