MP210UB 60W 6 Zones Mixing Amplifier with SD/USB/FM/4 Mic (with phantom power)

Name: MP210UB 60W 6 Zones Mixing Amplifier with SD/USB/FM/4 Mic (with phantom power)
Brand: Guangzhou DSPPA Audio Co., Ltd.

Features

● 100V & 4-16Ω,rated power 60W
● 6 zones with 100V output and with individual volume control
● Built-in MP3 player by USB & SD and FM tuner.
● 4 microphone inputs, Mic 1 with priority and muting function, Mic2-4 with XLR input, Mic3-4 with phantom power
● 3 aux line input & 1 aux line output and with chime output
● Each microphone and line input with individual volume control
● Bass and treble control
● Short circuit, overload, and high temp protection

Contact now Leave message Download

Introduction
Specification

This mixing amplifier is rated at 60W. 100V and 4-16 Ω speaker output are provided. There are 4 microphones inputs and 3 line inputs, FM, USB, SD audio sources. Bass and treble controls and master volume control are provided. This amplifier can be applied to different occasions, such as supermarket, classroom, etc. Extensive protection from short-circuit, overload and high temp is ensured. Automatic cooling system ensures the extreme quite sound system.

Model	MP-210UB	MP-310UB	MP-610UB	MP-1010UB
Rated Output	60W	120W	250W	350W
Output Regulation	Less than 3dB, from off-load to full load
Input sensitivity	Microphone :≤3mV (unbalanced)
	Line:≤300mV (unbalanced)
Frequency Response	80Hz-16kHz (±3dB)
Distortion	Less than 1% (at 1kHz, 1/3rated output voltage)
Ratio of Signal to Noise	MIC: more than 71dB
	LINE:more than 85dB
Tone	Bass:±10dB（at 100Hz）
	Treble:±10dB（at 10kHz）
Protection	DC voltage; overload; short-circuit.
Mute	Input signals from MIC 1 override other input signals
PowerSupply	AC 220V/50Hz
Power Consumption	120W	250W	500W	650W
Outer Packing Size(mm)	(L×W×H)520×430×195
Unit Size (mm)	(L×W×H)418×338×88
Gross Weight	11.7kg	13.5kg	16kg	17kg
Net Weight	9.7kg	11.5kg	14kg	15kg
