MP9813C Broadcast Partitioner

Name: MP9813C Broadcast Partitioner
Brand: Guangzhou DSPPA Audio Co., Ltd.

Features

● With 2-channel inputs (A & B), and 10-channel outputs.
● With override function.
● With ALL ON/OFF function control.
● With independent volume control for 10-channel zones (valid for the channel A input audio source).
● Support automatic switching of the corresponding channel to channel B when there is an alarm signal input.

Contact now Leave message Download

Introduction
Specification

MP9813C broadcast partitioner has 2 channels of inputs and 10 channels of outputs. With override function, it can input emergency broadcast signal. Besides, it has 10 zone selection buttons with independent volume control.

Model	MP9813C
Number of Channels	10 channels, which can be selected arbitrarily.
Input Capacity	70-100V, 10A
Output Capacity	70-100V, 5A for each channel
Alarm Signal	Valid for 0V (short circuit)
Protection	AC Fuse
Power	AC 220V/50Hz
Package Dimensions (mm)	(L×W×H) 530×440×195
Machine Dimensions (mm)	(L×W×H) 484×365×88
Gross Weight	11.2kg
Net Weight	9.4kg
