DM838T 7-inch In-Wall Amplifier Wall Panels (Tuya Optional)

Features

● Support dual partition music control, 7-inch touch screen, resolution 1024 * 600, easy to operate and control
● Music playback: support MP3, WAV, WMA, FLAC, DTS, APE, AC3, OGG and other audio formats.
● Bluetooth: support cell phone search to connect the host to play music
● External audio input: support for external audio sources into the machine, amplify the output
● Time calendar: support clock, calendar display function.
● Memory card function: external TF card, support for 32GB TF card
● USB function: external USB card, support 32GB USB
● Support wired network connection
● With RS485 interface
● Suitable for family, commercial area, children's room, etc.

Contact now Leave message Download

Introduction
Specification

The DM838T 8×10W 2 Zone 7-inch In-Wall Intelligent Music Control Host is a cutting-edge, wall-mounted system designed to deliver sophisticated audio management and an exceptional listening experience across two distinct zones, featuring support for a wide array of audio formats, Bluetooth connectivity for wireless music streaming, external audio input for expanded sound options, and optional wireless microphone functionality for impromptu karaoke sessions, which is perfect for scenarios such as home automation, retail environments, hospitality industry, office spaces and educational facilities.


Model		DM838K	DM838T
CPU		Quad-core Cortex 1.6GHZ
RAM		2G
ROM		16G
Wired Network		Support
Wireless Network		802.11b/g/n Wireless Protocol 150Mbps 2.4GHz
Speaker Output		8*(10-25W)(MAX) (Depending on hardware selected)
Output Impedance		4-8 Ω
System		Android 11
Screen		7-Inch 1024*600 Multi-Touch Control
Power Input		AC100~240V, 50/60Hz
RS485		Support
Amplifier Parameters	Frequency Response	20Hz-20Khz
	Signal-to-noise Ratio	98dB
Product Size		237.4111.827.6mm
Weight		1.49KG
Installation Mode		Front Preinstalled Cable Box
Operating Temperature		0℃~40℃
Operating Humidity		5% to 90%RH Non-Condensing
Zigbee		/	802.15.4 PHY/MAC Zigbee Network Protocol Stack
Wireless Protocol		Bluetooth	Bluetooth, Zigbee
Functional Support	Gateway Functions	/	Zigbee Gateway Capability, Can Connect 50+ Sub-devices with flexible control of multi-category Tuya ecosystem devices.
	Music Play	Support Bluetooth, TF Card, USB Disk, AUX Play music.
