D7233 Embedded Speech Chairman Unit

Features

● Compliant with IEC 60914 international standard.
● With internal magnetic high-fidelity speaker for auto mute when turned on, not easy to generate howling.
● 3.5mm stereo headphone jack for headphone connection, with adjustable headphone volume.
● Super strong anti-interference capability.
● With microphone switch button, and chairman priority button for the chairman unit.
● With the camera, it can realize auto camera tracking after setting through the digital conference system host

  • Introduction
  • Specification

The D7233/D7234 conference unit integrates functions such as speaking, voting, sign-in, self-test, tea application service and two-way intercom. Adopt cardioid directional condenser microphone, built-in internal magnetic speaker, headphone jack, with microphone on indicator ring and touch button light switch indication. It has the function of voice control switch in VOICE mode. Built-in digital high-speed processor and high-fidelity audio circuit. The unit with LCD capacitive touch screen can be operated by touch. The display can show the identity and working status of the chairman unit / VIP unit / common unit. With a variety of working modes, with echo cancellation,howling suppression, background squelch and other functions.

Model

D7233/D7234

Structure Type

Embedded

Effective Frequency of Gain Limit (±3dB)

Unit A to Unit B

50Hz-14kHz

Host Line to Unit

30Hz-18kHz

Unit to Host Line Output

40Hz-16kHz

Speaker Power

1.5W

Static Power Consumption

<5W

Maximum Power Consumption

8W

SNR

>76dB

Crosstalk Attenuation

>80dB

Harmonic Distortion

<0.3%

Headphone Output

9dBu,8-32Ω,3.5mm

Working Power

Host +48V PoE Power Supply

Unit Interface

Dante Network Interface

Microphone

Microphone Type

Electret Cardioid Capacitive Microphone

Sensitivity

-30dBV/pa

Input Impedance

2kΩ

Equivalent Noise

20dB(SPL)

Max. SPL.

125dB(THD<3%)

Package Size

500×200×180 mm

Machine Size (W×D×H)

80×80×145mm

Desktop Counterbore Size

81×81×3mm

Desktop Hole Size

73×70mm
