D950 Professional Intercom Microphone

Features:

● Electret condenser cardioid microphone; Indicator light on active microphone: when microphone is active, indicator light switches on
● Monitor speaker of desktop intercom, to monitoring the sound from windows microphone.
● Volume knob and on/off switch of monitor speaker for desktop intercom (with indicator).
● Volume knob and on/off switch of monitor speaker for windows intercom (with indicator).
● SPEAKER: Connection for window intercom, 3.5 mm stereo jack
● LINE IN: 3.5 mm jack for reproduction through window intercom
● REC OUT: 1 REC, 3.5 mm stereo jack
● Power on/off switch
● POWER INPUT DC12V
● Monitor speaker of window intercom, to monitoring the sound from desktop microphone.
● Microphone of window intercom
● Call: Press this key to give call indicator to desktop intercom.
● Bracket for window intercom (Option 1)
  • Introduction
  • Specification
  • Connection

Window intercom to ease communication through counter windows, glass partitions or windows in box offices, banks, offices, control points, private accesses, car parks, etc. Clear sound for voice. Easy to use.


TECHNICAL DATA SHEET

CHARACTERISTICS


Window intercom microphone

Quality sound with anti-feedback processor.

Duplex two-way sound with communication control.

Independent volume and mute button for window and interior intercom

Easy to use.

CONTROLS

On/off

Independent window and interior volume

Windows and interior mute button

FUNCTIONS

Automatic communication control, internal intercom priority

Anti-feedback processor

LED power indicators on desktop intercom

Power 2 x 5 W

Optimum distance for speaking into window intercom microphone 20 cm

The window intercom can be hung or stuck on the glass with the provided.

double-sided adhesive pads.

INPUTS

1 microphone-loudspeaker connection for window intercom, 3.5 mm stereo jack

1 line, 3.5 mm jack for reproduction through window intercom

OUTPUT

1 REC, 3.5 mm stereo jack

POWER SUPPLY

12 V DC, 1 A with adapter included

CABLE

2.4 m cable for window intercom

DIMENSIONS

Desktop intercom: 141 x 62 x 142 mm depth

Gooseneck microphone: 340mm height

Window intercom:

Option 1:84 x 124 x 37 mm depth (with bracket)

Option 2:145 x 100 x100 mm depth

WEIGHT

1.2 kg

ACCESSORIES

Foam windshield

Adhesive pad for window intercom installation
