DMX12-Channel Audio Mixer

Name: DMX12-Channel Audio Mixer
Brand: Guangzhou DSPPA Audio Co., Ltd.

Features

● DMX08, DMX12, DM16
● 8, 12, 16 XLR balanced mono channels input.
● Ultra-low noise circuit design.
● 3 equalization adjustments per channel MUTE mute switch
● 60MM smooth fader attenuator.
● 1 set of return, 1 set of RAC output.
● 48V phantom power supply.
● 16 kinds of DSP digital effector. USB , Bluetooth USB recording.
● LED display , Ten-segment three-color level light
● 1 set of stereo bus output + 2 sets of AUX bus output

Contact now Leave message Download

Introduction
Specification
Connection

Items	DMX08	DMX12	DMX16
MAX. Output Level	18dB
S/N	≥83dB
THD	≤0.02% @0dB 1KHz
Frequency Response	20Hz~20KHz±0.5dB
Channel Crosstalk	＜-75dB @ 1KHz
Input Impedance MIC	600Ω
LINE	10KΩ
Output Impedance	100Ω
MIC IN	-60dB
LINE IN	-40dB
Stereo Input Impedance	10KΩ	/
Channel Gain	-30dB	/
3-band EQ	±15dB	/
HI	12KHz 15dB ±3dB	/
MID	2.5KHz 15dB ±3dB	/
LOW	80Hz 15dB ±3dB	/
Output Power	30W	/
Power Supply	100V-240V/50Hz	/
Package Dimensions	440×440×165mm	555×440×165mm	670×440×165mm
Product Dimensions	385×367×100mm	505×367×100mm	620×367×100mm
Gross Weight	5kg	6kg	7.5kg
Net Weight	4kg	5kg	6.2kg
