DSP3008H 2-Way Weatherproof Commecial Loudspeaker


● Rated power(100v):15W/30W/60W/120W
● Rated power(70v):7.5W/15W/30W/60W/120W
● Rated power(8Ω): 120W
● Sensitivity(1W/1M): 101dB±3dB
● sound beam angle: <110°
● Freq. Response: 80Hz -18KHz
● ● Speaker unit:8''x1+1.5''x1
● Water resistance: IP55
● Dimension: 390×370×330mm
● Net weight:9.1kg
● High-strength ABS material appearance, aluminum mesh
● Long transmission distance, small size, loud and clear speaker,

  • Introduction
  • Specification

The DSP3008H is a compact coaxial drive, 2-way, highly weather-resistant, full-range PA speaker system ideal for voice and music filling in a variety of applications, including sports facilities, racetracks, stadiums, playgrounds, rodeos, ice rinks, themed entertainment venues, cruise ships, water parks, outdoor background music/paging systems, swimming pools, and a variety of other outdoor or indoor venue types.



Rated Power (100V)


Rated Power (70V)


Peak Power



70V / 100V / 8Ω

Sensitivity (1W/1M)


Frequency Response


Radiation Angle


Driver Unit

8”×1 , 1.5”×1

Product Size (H×W×D)




Product Weight

9.1 kg

Production Level

IP55 (Reference)

Package Size


Housing Materials

Plastic Shell + Aluminum Mesh Cover + Iron Bracket
