DSS1417 Active Directional Speaker System

Name: DSS1417 Active Directional Speaker System
Brand: Guangzhou DSPPA Audio Co., Ltd.

Features

● Equipped with an ultra-thin transducer unit, making the system exceptionally slim.
● With strong directivity and ultra-narrow beam angle to achieve optimal sound control and prevent interference between different sounds.
● Support built-in audio playback, including USB flash drive/TF card/Bluetooth 5.0.
● Adopt advanced pre-processing algorithm for low distortion.
● Support virtual sound source, with high-quality stereo sound.
● Support remote control for efficient volume control.
● Support infrared control mode (Silent/Pause/Play/Normal mode).
● Easy and flexible to install, can be installed on ceilings or with brackets at any angle.

Contact now Leave message Download

Introduction
Specification

DSS1417 is a directional active speaker system. As the ultrasonic wavelength is only a few millimeters, much smaller than that of the speaker, it can produce nearly linear narrow beam. Ultrasonic wave directional loudspeaker can realize directional spreading of sound in the air just like a flashlight beam, and control the sound waves spreading in a specified area, so that the area has a large sound, while other areas have smaller sound or even no sound.

Model	DSS1417
Speaker Part
Maximum Output	50W
Sound Pressure Level	95dB@1kHz/1m
Harmonic Distortion	0.5%
Transmission Distance	＜20m
Transmission Angle	±15°
Input	24V 3A
Dimensions	26313228mm
Net Weight	850g
Power Driver Part
Distortion	≤0.5%
Power	72W
Input	24V 3A
Dimensions	17511845mm
Audio Source	Support BT input, U disk, TF card playback
Input Interface	3.5-inch audio input
Output Interface	One set of audio signal output
Control Mode	Infrared induction control/silence/reboot mode for choice
Remote Control	Support central control analog remote control
