MAG6265 IP Network Video Intercom Terminal

Name: MAG6265 IP Network Video Intercom Terminal
Brand: Guangzhou DSPPA Audio Co., Ltd.

Features

● IP network on-wall intercom terminal
● Aluminum alloy elegant and durable design
● Built-in 2W speaker of high audio definition
● Built-in RS-485 interface for third party control
● 2x20W speaker outputs, 2 AUX outputs
● Built-in 130W 720P camera for video intercom
● Built-in SD card, support offline recording

Contact now Leave message Download

Introduction
Specification
Connection

The MAG6265 is a network visual intercom device for bi-directional intercom with the visual broadcast intercom management host. It can be used in LAN or WAN (depending on the actual situation) via network connection. The remote audio data stream can be output by native audio signal by intelligent control from host. It is suitable for schools, squares, crowded roads and accident-prone areas, when or help are need in an emergency. Press the call button to immediately talk to the monitoring Center. Personnel can also understand the situation through the front camera and broadcast.

Network interface: standard RJ45 interface	Network protocol TCP/IP、UDP、IGMP、RTP
Audio sampling rate: 8K～44.1K Hz	Audio mode: 16bit stereo CD quality
Broadcast audio format: MP3	Output frequency: 20 Hz～20K Hz
HD: < 1%	SNR: ≥ 70dB
Built-in MIC impedance and power: 8Ω，2W	MIC input sensitivity: < 20mV
Audio data stream: 16Kb～192Kb	HD camera 130W
Video data stream: 128Kb～2Mb	Standby power consumption < 1W
Input power: DC12V/25W	Working temp: -20℃ ～ +80℃
Working humidity: 10% ～ 90%	Dimension: 18510845 (LxWxH)
Recommended installation height: The top of the device is about 1.6 meters from the ground.
