MAG6408 IP Network Column Alarm Terminal

Features

● IP network outdoor SOS intercom terminal
● Waterproof design, durable for use
● 1 AUX input, 2 Mic inputs, 1 AUX output
● Support USB and SD for local audio playing
● 1 EMC output and 1 short-circuit output
● Built-in 2x25W digital amplifier for speaker output
● Support music playing, paging and alarm from the system
● With emergency flashing light, can be found easily

  • Introduction
  • Specification
  • Connection

The network column alarm terminal MAG6408 is a fully digital analog-to-digital conversion signal processor based on the TCP/IP transmission protocol. At the same time, using the network as the signal transmission medium, it can be combined with the network system to realize an outdoor help alarm interactive system. With dual network redundancy design, it can be connected to any place that the network can reach. It is suitable for broadcasting needs in schools, banks and urban security and other fields.

Items

Indicators

AUX IN

Input Sensitivity

350 mV±50mV

Frequency Response

20Hz-16kHz(±3dB)

Distortion

≤0.5%

Noise

1.7mV

SNR

≥77 dB

AUX OUT

Output Sensitivity

1000mV±100mV

Frequency Response

20Hz-20KHz(±3dB)

Distortion

≤0.5%

Noise

0.12 mV

SNR

≥78 dB

Maximum Output Power of Built-in Amplifier

Independent Channel Mode

25W/4Ω

BTL Mode

50W/8Ω

Maximum Harmonic Distortion of Built-in Amplifier

≤0.7%

Built-in Speaker

2W

MICIN

Input Sensitivity

5mV±1mV

Frequency Response

20Hz-16kHz(±3dB)

Distortion

≤0.7%

Noise

1.7 mV

SNR

≥77 dB

MP3

Output Sensitivity

11V±1V

Frequency Response

20Hz-16kHz(±3dB)

Distortion

≤0.6%

Noise

1.5mV

SNR

≥77dB

Supported External USB Capacity

32GB

Power Supply

AC220V/50Hz

Overcurrent,Overheating,Overvoltage andUndervoltageProtection

Satisfied

Package Dimensions (L×W×H mm)

500×480×2000

Machine Dimensions (L×W×H mm)

420×400×1910

Gross Weight

26

Net Weight

24.5



MAG6408 IP Network Column Alarm Terminal
