MP2500 650W 70V-100V 4-16 ohm Amplifier

Name: MP2500 650W 70V-100V 4-16 ohm Amplifier
Brand: Guangzhou DSPPA Audio Co., Ltd.

Features

● Rack mount amplifier in 2U height
● 70V, 100V and 4-16 ohm speaker outputs
● Isolated transformer for human safety operation
● Rated power 650W, 5 LED indicator for status display
● Indications for power, signal, clip, protection and temp
● Reliable protection from overheat, overload, clip & short circuit
● XLR socket and 6.35mm jack for additional mixer or amplifier link
● Excellent device of radiator cooling fan ensures working effectively

Contact now Leave message Download

Introduction
Specification
Connection

This amplifier is designed for commercial and industrial public address applications. Rack mount design in 2U type and rated power is 650W.

Both balanced and unbalanced line inputs are available for each channel. Balanced line output feeds to another power amplifier as well as secures the signal transmission is less noise and longer distance. 70V, 100V and 4-16ohm speaker outputs are convenient for installation when selection different speaker matching. A master volume control is included. Complete protection includes clip, short circuit, high temp and overload. With indications for power, signal, clip, protection and temp. This product belongs to power amps for pa systems, and power amps for sale.
MP2500 650W 70V-100V 4-16 ohm Amplifier

Model	MP2500
Rated power	650W
Rated output voltage	70V/100V/4-16 ohm
Inputsensitivity	0dBu
S/N Ratio	> 80dB
Damping Factor	200:1
Input CMRR	Greater than 90dB
THD into 4W/1kHz	<0.3%
Frequency response	50Hz ~15kHz (±3dB)
Slew Rate	>15V/microsecond
Power Consumption	700W
Powerrequirement	AC220~240V/50~60Hz
Unit Size (mm)	(L×W×H)483´380x88
Netweight	39Kg
