PC1076 Power Sequence Controller

Name: PC1076 Power Sequence Controller
Brand: Guangzhou DSPPA Audio Co., Ltd.

Features

● Turn on or off the power of 16-channel controlled devices in sequence.
● Support auto or manual control through a timer.
● Support auto power-on with a short-circuit signal.
● With a total socket capacity of 3.5kVA.
● Can display the working voltage.
● Can support remote control of PC and network public address system host.
● Adopt a hand-in-hand connection method.

Contact now Leave message Download

Introduction
Specification

This product is a power sequence controller, which can turn on or off the power of 16 channels of controlled devices in sequence, with auto and manual control. It can turn on the power when it receives a short-circuit signal. Also, it can support remote control of PC and network public address system host.

Model	PC1076
Power Socket Output Capacity	Total capacity 3.5kVA, 16 channels. 220V, maximum output current 10A per socket
Timer Control Signal	Network trigger signal
Action Interval	About 0.5s
Working Power	AC 220V/50Hz
Protection	F1AL
Package Dimensions (mm)	(L×W×H) 555×455×185
Machine Dimensions (mm)	(L×W×H) 484×320×88
Gross Weight	9.2kg
Net Weight	7.4kg
