PAVA9008 16 Zones Remote Paging Microphone

Features

● Support 16-zone paging, single- or multi-zone paging, group paging and all-zone paging.
● With DIP address settings.
● Powered by bus and DC48V.
● With 1 AUX IN for paging signal input.
● With 2-digit DIP switches for selecting AUX or Local MIC IN.
● Support redundant wiring of lines.
● The system can support up to 8 devices (remote paging microphones or fireman microphones). With RJ45 ports, these microphones are powered by bus communication port and connected hand in hand.
● Support self-defined group functions for buttons.
● If the host is connected to a device via a single port, it can support a maximum transmission distance of 600 meters. The host can be cascaded to up to three devices via a single port, with a maximum transmission distance of 300 meters.

Contact now Leave message Download

Introduction
Specification

EN54-16 fire emergency broadcasting system provides manual operation and timing programming, and gives priority to the former over the latter; supports real-time monitoring of equipment operating status and recording of operating logs. It meets the relevant standard of “EN54-16 Voice Alarm Control and Indicating Equipment”. The broadcasting system can be used for fire emergency broadcasting, daily service broadcasting and background broadcasting; this system is positioned as a small emergency broadcasting system, mainly used in small shopping malls, small office buildings and exhibition halls, etc.

PAVA9008/PAVA9008E Remote Paging Microphone / Expansion Keyboard is used to page each zone of the host PAVA9500.

Model	PAVA9008	PAVA9008E
Microphone Input Sensitivity	30mV 600Ω	——
Line Input Sensitivity	1000mV 10kΩ	——
Frequency Response	80Hz~15kHz (±3dB)	——
Distortion	<1%	——
S/N Ratio	>75dB (A-Weighted)	——
PoE Power	(48±3)V/0.1A	——
Phantom Power	——	(12~24)V/0.1A
Interface	RJ45
Package Dimensions	415×306×116mm	355×266×116mm
Machine Dimensions	166×220×54mm	166×161×54mm
Gross Weight	1.7kg	1.3kg kg
Net Weight	1.25kg	0.8kg
