MAG6107CVG 30W Network Indoor Wall Mount Speaker

Name: MAG6107CVG 30W Network Indoor Wall Mount Speaker
Brand: Guangzhou DSPPA Audio Co., Ltd.

Features

● With integrated design of network terminal processor and high fidelity speaker;
● Built-in industrial-grade special network audio decoding chip, can play background music from the system host, emergency paging, alarm signals, etc. The network programme source has more than 7 levels of priority level management function, which is divided into three major categories: background broadcasting, business broadcasting and emergency broadcasting;
● Can be applied at any place with access to network;
● Support the decoding of 16-bit digital audio stream with the maximum sampling rate of 48kHz;
● Built-in 2×30W digital power amplifier with sub-speaker interface to meet the needs of classroom teaching;
● 2.4G wireless microphone broadcast: used in conjunction with 2.4G wireless microphone, mainly used in wireless multimedia teaching;
● Headset wireless microphone, support one teacher to carry one microphone;
● Support webpage modification of IP address and other parameters, or remote server modification through upgrade tools.
● Bluetooth music broadcasting: It can accept the Bluetooth signal of the mobile phone for Bluetooth music broadcasting.
● Support one local line input for connecting to a local all-in-one machine or other audio source equipment to expand program sources;
● Support one local line output to expand the power of the machine;
● It has a 100V backup input interface, which can realize 100V seamless backup switching function when the network is disconnected and the power is disconnected;
● The audio source priority is adjustable and supports two modes: network priority and network and local mixing;

Contact now Leave message Download

Introduction
Specification

MAG6107CVG Network Indoor Speaker is a modern network playback terminal based on TCP/IP transmission protocol, which has a fully digital analog-to-digital conversion signal processor combined with high-fidelity speakers to realize the integrated design of the processor and the speaker. The remote audio data stream can output audio signals through this machine, and directly emit sound from the speaker, which is intelligently controlled by the host;It has a built-in 2.4G transmission mode and a transmission box with a microphone, which mainly realizes 2.4G transmission function and can be used for local broadcasting, wireless multimedia teaching, wireless conference, etc.

Model			MAG6107CVG
Acoustic System		Speaker Dimension	Treble 2” Bass 5”
		Max. SPL (1 m)	104±3dB
		Frequency Response	120Hz-20kHz
		Rated Power (RMS)	30W
Amplifier System	NET Playback Built-in Amplifier	Min. Source Electromagnetic Force	-10dB
		Frequency Response	25Hz-18kHz
		Distortion	≤0.5%
		SNR	≥75dB
Rated Output Power			30W*2
Output Method			4Ω Constant Resistant Output
Auxiliary Output Level			≥900mv
Auxiliary Output Frequency Response			20Hz-20kHz
Auxiliary Output Distortion			≤0.55%
Auxiliary Output SNR			≥75dB
Auxiliary Input Minimum Source Electromotive Force			Line≤350mv (unbalanced)
Auxiliary Input Frequency Response			20Hz-20kHz
Auxiliary Input Total Harmonic Distortion			≤0.85%
Auxiliary Input SNR			Line Output: ≥75dB (Broadband)
Protection			AC fuse, overcurrent, overheating, overvoltage, undervoltage, overload and short circuit
Power Supply			AC220V / 50Hz
Rated Power Consumption			89W
Package Size (W×D×Hmm)			450×365×280mm
Product Size (W×D×H)			292×212×165mm
Gross Weight (2PCS)			10.5kg (2PCS)
Net Weight			4.5kg
