D6226 Desktop Array Delegate Unit

Features

● Built-in 17 highly directional and highly sensitive array microphone with high resolution degree of human voice
● Touch-screen on/off button and chairman priority button
● 3.5 mm earphone output on the left side
● 8 pin conference cable on the bottom, support cascade connection with host D6201
● Support simultaneous use with D6221/6222
● Pickup distance up to 80cm, simple and exquisite

  • Introduction
  • Specification

Desktop array unit adopts microphone with high directivity, high sensitivity and high degree of resolution of human voice. Pickup angle, pickup phase, pickup distance and high fidelity line are designed through array combination which is an effective combination of advanced control technique and audio processing technique. With beautiful and precise appearance, it satisfies the need of different customers. It has 3.5mm earphone interface and camera tracking function. It can be integrated with the D6201 series of conference systems to form a comprehensive solution for high-quality conference systems.
D6226 Desktop Array Delegate Unit

Frequency Response

80Hz-16KHz (≤±3dB)


MIC Directivity

Directional Broadband Type

MIC Sensitivity

200mV/Pa


SNR

≥71dB


Dynamic Range

≥20dB


THD

≤1%


Max Power Consumption

1W


Cascade connection wire

8-core conference wire


Color

Black


Installation

Desktop


Package Size (mm)

(L×W×H) 345×135×135


Machine Size (mm)

(L×W×H) )297×67×57


Gross Weight (Kg)

1

Net Weight (Kg)

0.5
