DSP204H 30W Explosion-proof Horn Speaker

Features

● Explosion-proof type: Fireproof
● Explosion-proof marking: ExdIICT6
● Degree of protection: IP54
● 100V/4~16Ω terminal
● Max SPL: 118±2dB
● Wide Freq.Resp.: 400Hz–10kHz
● High sensitivity: 105±2dB

  • Introduction
  • Specification
  • Connection

DSP 204H features superior fireproof performance and sufficient mechanical strength. It is with high sensitivity and electricity/sound efficiency. This product is used for high fire resistance, generates no hazardous gas or environmental pollution.

DSP 204H is suitable for broadcasting, paging and emergency broadcasting in chemical plants, gas stations and the like which have a risk of explosion due to methane mixture, petroleum and other dangerous gas. It is applicable to a site where Class II, T6 explosive atmosphere exists or steam or air is generated.

MODEL

DSP204H

Rated Power

30W

Line Voltage

70/100V

Sensitivity(1M,1W)

105±2dB

Max SPL(1M)

118±2dB

Freq. Resp

400Hz–10kHz

Dimension(L×W×H)

252*252*355mm

Weight

7.2kg


DSP204H 30W Explosion-proof Horn Speaker
