MP1715T PA System Program Timing Player New

Features

● With a 4.3" capacitive LCD touch screen, available in Chinese and English, and built-in 16G storage.
● With 1 program player, 1 line input, 1 Bluetooth input, and 1 line output.
● With independent volume control for 3 audio sources, mixed output for 3 audio sources, and total volume control.
● USB interface: You can import the configuration content (including songs or timing points, etc.) to the machine via a USB flash drive; you can also export the configuration content from the machine to a USB flash drive.
● You can upgrade the latest software through a USB flash drive to play music programs on the USB flash drive and play up to 48KHz 16-bit songs in the MP3/WAV audio format.
● With an RJ45 connector (connected to a PC to download and update songs and timing points, as well as control the machine).
● With 5 sets of timing plans (which can be scheduled by weekly cycle or on a specified date) editable, up to 200 timing points for each timing plan, up to 20 songs for each timing point; an end time can be set for the timing point.
● With 1 AC220V/2000W power output socket, which can be controlled on or off by the timing point.
● It has the function of automatically switching on the timing power early within 1-60 seconds (time can be set) before the timing point comes.
● With 1 short circuit signal output interface linked to the timing power output.
● With a 100-meter wireless remote control, 12 programmable buttons, user-defined one-key song selection and power output.
● The distributed central control system controls the operation of the local MP3 player, various volume adjustments, and analogue remote control 12-key triggering functions.
● Can be connected to a headset to monitor the playback status.
● With level indication for output indication of all signal sources.
● Available in Chinese and English, with optional backlight time.
● The PC software allows centralized control of multiple local machines.

  • Introduction
  • Specification
  • Connection

This product is a MP3 timing player with 4.3” capacitive LCD touch screen and level indication. It supports several audio sources, such as program player, line input, and Bluetooth input. It provides 5 editable timing plans, a maximum of 200 timing points for each timing plan, and a maximum of 20 songs for each timing point. Also, the device can be controlled on or off by the timing point.

Model

MP1715T

Display Screen

4.3"

MP3 Input Sensitivity

300±50mV

Line Input Sensitivity

250±50mV

Line Output Voltage

1000±100mV

Headset Monitoring Level

1000±100mV

Frequency Response

20-20kHZ (±3dB)

Distortion

≤0.3%

S/N Ratio

≥ 75 (A) dB

Timing Plan

5 weekly plans and 1 daily plan

Operating Power

AC 220V/50Hz

Package Dimensions (mm)

(L×W×H) 530×440×195

Machine Dimensions (mm)

(L×W×H) 483×325×88

Gross Weight

6.3kg

Net Weight

4.8kg
