DSP255 Outdoor Waterproof Column Speaker

Features

● IP66 waterproof level
● Power taps at 8w-15w@100V
● Max SPL: 97±2dB
● High sensitivity: 88±2dB
● Wide Freq.Resp.:140Hz-14kHz
● Built-in 100v/70v transformer
● Aluminum enclosure & grille
● Weatherproof column type loudspeaker
● 2 units 3”x5” and 1 unit 2.5” full range drivers

  • Introduction
  • Specification

The DSP255 is a weatherproof outdoor column speaker with a 70v/100v transformer built-in. The 70v/100v transmission is realized in a high-voltage, low-current mode, which makes longer distance transmission and parallel connection of multiple loudspeakers possible.

The built-in 2 units 3''x5'' and 1 unit 2.5'' full range speaker drivers are designed of wide frequency response 140-14,000Hz, the multiple power taps of 8W & 15W could meet different applications varies from room size and ambient noise surroundings

The net cover is made of aluminum and would not rust, it is also designed of weatherproof and heavy damage proof finish; long-term durability, high sensitivity, clear and sonorous sound. Easy and secure wall mount installation in outdoor area through the supplied pair of metal mounting brackets.

It is ideal choice for industrial and commercial applications in the outdoor area of train station, shopping mall, parking area and factory where background music and paging is needed.

Model

DSP255

Full-range

3”×5”×2, 2.5”×1

Rated Power

8W

Max Power

15W

Line Voltage

70/100V

Sensitivity(1M,1W)

88±2dB

Max SPL(1M)

97±2dB

Freq. Resp

140-14,000Hz

Dimension(L×W×H)

112×112×400mm

Weight

2.2kg
