DSP3254EN 10W EN54 Fireproof Ceiling Speaker

Features

● Built-in 100v transformer
● In-ceiling type loudspeaker
● 6.5” paper cone waterproof driver
● Rate power 10W with optional power taps
● High-class steel and form by stamping
● Leaded wire case and ceramic terminals for fireproofing
● Comply with EN54-24 requirements

  • Introduction
  • Specification
  • Connection

The DSP3254EN is a ceiling speaker designed for voice evacuation systems, which comply with EN54-24 requirements. It has a 100v transformer built in. The 100v transmission is realized in a high-voltage, low-current mode, which makes longer distance transmission and parallel connection of multiple loudspeakers possible.


The built-in 6.5” speaker driver is designed of wide frequency response (90-20,000Hz), the multiple terminals 2.5W-10W can be applied to different occasions vary in area sizes and background noises; It is made of high-class steel and fixed by stamping, which ensures long-term durability, and will never be out of shape; Equipped with leaded wire case which is hard to burn for fireproofing; Spring clip clamp makes the easy and secure installation possible; Driver surround excellent damping, long life, clear and sonorous sounds.

It is an ideal choice for industrial and commercial applications in hotel, school, office and factory where background music and paging is needed.

DSP3254EN 10W EN54 Fireproof Ceiling Speaker

MODEL

DSP3254EN

FULL-RANGE

6.5”

RATED POWER

10W

LINE INPUT

100V

SENSITIVITY(1M,1W)

91.7±2dB

MAX SPL(1M)

101.7±2dB

FREQ. RESPONSE

90-20,000Hz

CUTOUT SIZE

Ø185 - Ø200mm

DEMENSIONS(H x W x L)

141 x Ø211mm

WEIGHT

1.6kg

DSP3254EN 10W EN54 Fireproof Ceiling Speaker
