D5815 D5821 D5822 D5823 D5824 True Diversity Wireless Microphone

Features

● Dual-channel PLL design.
● UHF200 channel PLL digital lock automatic communication function.
● Adopt IR frequency pairing.
● With display screen (to display frequency, channel, squelch, level, etc.).
● With volume control for each channel.
● AF output (using “XLR” sockets for separate output and mixed output).

  • Introduction
  • Specification

This product is a professional wireless microphone system. D5815 is the wireless microphone receiver, which can be combined with several kinds of transmitters to form a wireless microphone system. The combination set includes D5821 (UHF Wireless Microphone System+2 Handheld Wireless Microphones), D5822 (UHF Wireless Microphone System+2 Clip Wireless Microphones+2 Waistband Transmitters), D5823 (UHF Wireless Microphone System+2 Headset Wireless Microphones+2 Waistband Transmitters), and D5824 (UHF Wireless Microphone System+2 Desktop Wireless Microphones).



System Index

Parameters

Frequency Range

632-661.25MHz

Number of Channels

100

Frequency Step

250KHz

Dynamic Range

82dB

Maximum Frequency Deviation

±45KHz

Audio Frequency Response

120Hz-15KHz (±3dB)

SNR

>70dB

Distortion

≤1%

Working Temperature

-10℃+40℃

Effective Range

Maximum 300m (in open environment)

Package Dimensions (L×W×H)

530×335×330mm

D5821 Gross Weight

5.2kg

D5822/D5823 Gross Weight

4.6kg

D5824 Gross Weight

5.3kg

Receiver

Wireless Interface

BNC/50Ω

Sensitivity

-100dBm

Display Method

Display screen

Working Power

DC12V ,600mA

Package Dimensions (L×W×H)

530×335×100mm

Machine Dimensions

430×176×44mm

Gross Weight

3.9kg

Net Weight

2.3kg

Transmitter

Antenna Method

1/4 wave whip antenna for the waistband transmitter, and built-in onboard antenna for the handheld microphone.

Output Power

High power 14dBm; low power 6dBm

Spur Suppression

-60dB

Power Supply

2 AA 1.5V alkaline batteries

Endurance

More than 10 hours at 14dBm; more than 15 hours at 6dBm.

Desktop MIC Rod Length

420mm

Display Method

Display screen

Handheld MIC Dimensions (Maximum Diameter × Length)

50×265mm (Handheld part diameter 34~38mm)

Waistband Transmitter Dimensions

110×64×25mm (excluding antenna length, 80mm more if included)

Desktop MIC Dimensions

151×100×55mm

Net Weight of Desktop MIC

0.45kg

Net Weight of Handheld MIC

0.45kg

Net Weight of Waistband Transmitter

0.1kg
