D5817 D5881 D5882 D5883 D5884 True Diversity Wireless Microphone

Features

● 8-channel PLL design.
● UHF200 channel PLL digital lock automatic communication function.
● Adopt IR frequency pairing.
● With display screen (to display frequency, channel, squelch, level, etc.).
● With volume control for each channel.
● AF output (using “XLR” sockets for separate output and mixed output).

  • Introduction
  • Specification

This product is a professional wireless microphone system. D5817 is the wireless microphone receiver, which can be combined with several kinds of transmitters to form a wireless microphone system. The combination set includes D5881 (UHF Wireless Microphone System+8 Handheld Wireless Microphones), D5882 (UHF Wireless Microphone System+8 Clip Wireless Microphones+8 Waistband Transmitters), D5883 (UHF Wireless Microphone System+8 Headset Wireless Microphones+8 Waistband Transmitters), and D5884 (UHF Wireless Microphone System+8 Desktop Wireless Microphones).


System Index

Parameters

Frequency Range

632-695.25MHz

Modulation Mode

Broadband FM

Adjustable Range

60MHz

Number of Channels

200

Channel Interval

250KHz

Frequency Stability

Within ±0.005%

Dynamic Range

88dB

Maximum Frequency Deviation

±45KHz

Audio Frequency Response

120Hz-16KHz(±3dB)

SNR

>73dB

Distortion

≤1%

Working Temperature

-10℃+40℃

Effective Range

150-200m (in open environment)

Package Dimensions (L×W×H)

530×335×330mm

D5881 Gross Weight

9kg

D5882/D5883 Gross Weight

7.4kg

D5884 Gross Weight

9.6kg

Receiver

Wireless Interface

BNC/50Ω

Sensitivity

-100dBm

Spur Suppression

≥75dB

Display Method

Display Screen

Working Power

DC12V ,600mA

Package Dimensions (L×W×H)

530×335×145mm

Machine Dimensions

430×176×88mm

Gross Weight

5.2kg

Net Weight

3.3kg

Transmitter

Antenna Method

1/4 wave whip antenna for the waistband transmitter, and built-in onboard antenna for the handheld microphone.

Output Power

High power 14dBm; low power 6dBm

Spur Suppression

-60dB

Power Supply

2 AA 1.5V alkaline batteries

Endurance

More than 10 hours at 14dBm; more than 15 hours at 6dBm.

Desktop MIC Rod Length

420mm

Display Method

Display Screen

Handheld MIC Dimensions (Maximum Diameter × Length)

50×265mm (Handheld part diameter 34~38mm)

Waistband Transmitter Dimensions

110×64×25mm (excluding antenna length, 80mm more if included)

Desktop MIC Dimensions

151×100×55mm

Net Weight of Desktop MIC

0.45kg

Net Weight of Handheld MIC

0.45kg

Net Weight of Waistband Transmitter

0.1kg
