DSP9100 7U IP Network PA System Server

Features

● 10/100M/1000M self-adapting, support DHCP/IP settings, LAN and WAN.
● Professional rack case design and aluminium alloy structure, with high anti-magnetic, anti-dust, anti-impact ability.
● Adopt 17.3 inch touch screen (Only for 7U), built-in large capacity SSD with sensitive touch, fast reading and writing speed, low power consumption and others.
● Built-in professional IP broadcast intercom management software to configure, manage and maintain all terminal devices, and monitor devices status.
● Multiple USB and VGA interfaces, convenient for expansion.
● Hidden push-pull keyboard and TouchPad for 7U.
● 3C certificate, stable and reliable.

  • Introduction
  • Specification

The IP Broadcast Intercom Server adopts industrial host. The system is stable and reliable with SSD and aluminum alloy panel. Working 24 hours a day, it can operate stably in low and high temperature for a long time. With Ethernet hardware, additional line maintenance is not required for the whole system. It has high performance, low power consumption and can run steadily for a long time. With professional server software, it can configure, manage and maintain all terminal devices. The server is divided into two forms of 7U and 2U to meet different requirements.


Model

DSP9100 (2U)

DSP9100 (7U)

Display Screen

/

17.3" 1920×1080, resistive touch screen

Video Interface

VGA, HDMI

VGA

USB

Front: USB×2, rear: USB×4

Supported Protocols

TCP/IP, UDP, ICMP, IGMP (Multicast)

Network

RTL8111F Gigabit Ethernet Controller, supporting WoL/PXE

Power Input

ATX power supply (AC180-240V~/47-63Hz/7/3.5A)

Working Environment

-10℃~50℃, ≤90%RH (non-condensing)

Package Size(H×W×D)

160×535×470mm

470×535×365mm

Product Size (H×W×D)

88×483×335mm

308×483×340mm

Gross Weight

7.8kg

23.4kg

Net Weight

5.9kg

13.4kg
