LA-4240+LA-15SUB Multipurpose Portable Column Array Speaker System

Features

● Designed to be waterproof for all-weather outdoor use, with a protective shell made entirely of aluminum;
● Produces clear, bright sound quality, featuring high mid-tone reproduction and robust, powerful bass;
● Installation is straightforward and convenient, with a long-range outdoor projection distance;
● Equipped with built-in DSP audio processing and an efficient active power amplifier module;
● The system includes a subwoofer paired with two sound columns, forming a high-power sound reinforcement system with various adjustable programs;
● Suitable for a range of settings, including churches, museums, live sound reinforcement, train stations, airports, sports facilities, legislative buildings, conference rooms, lecture halls, shopping malls, and A/V demonstration halls.

  • Introduction
  • Specification

The LA-4240 is a compact linear sound speaker with 4.5” full range speaker unit, designed for voice and music applications, while the LA-15SUB is an active subwoofer with digital signal processing, well-designed 15” woofer that delivers the highest output, best sound performance. The golden combination of two LA-4240 and one LA-15SUB has a clear bright sound quality and strong bass, easy and convenient installation, its sound pressure level is far higher than the same level of products. With impressive outdoor projection distance, this system is ideal for a variety of applications, including use in churches, museums, live sound reinforcement, train stations, airports, sports facilities, legislative buildings, conference rooms, lecture halls, shopping malls, and A/V demonstration halls.


Model

LA-4240

Frequency Response (±3dB)

110Hz~17kHz

Frequency Range (-10dB)

80Hz~20kHz

NominalDirectionality (-6dB)

Horizontal 120°×Vertical 160°

Speaker Unit

4×4.5” Full Range Unit (Per)

RatedImpedance

Sensitivity (1m/1W)

99dB

Rated Power (AES/Peak)

240W / 960W

Max.SPL

122dB (continuous) / 128dB (Peak)

Product Dimensions (H×W×D)

496mm×125mm×138mm

Net Weight

6.8kg


Model

LA-15SUB

Frequency Response (±3dB)

40Hz~250Hz

Frequency Range (-10dB)

35Hz~300Hz

Speaker Unit

1×15”Bass (220magenetic/4”(100mm)voice coil)

Rated Power (AES/Peak)

600W / 2400W

RatedImpedance

Max.SPL

126dB (continuous) / 132dB (Peak)

Amplifier Module

Input Working Voltage

AC90V~260V PFC, 50Hz/60Hz

Power Input Interface

Power CON

Output Power

4Ω/600W + 8Ω/1200W

Frequency Response (0/-0.5dB)

20Hz~20kHz

SNR

≥101dB (20Hz~20kHz, A-weighting)

THD

≤0.05

Damping Factor

≥600@100Hz

Amplifier Output Interface

One four-core professional speaker socket, output +1, -1

DSP Module Sampling Frequency

96k / 24bit

Input Sensitivity@80

1.2V/4dBu

Input Output Interface

XLR-F/M

DSP Channels

1 In 2 Out DSP

Preset Program

8 PCS

Product Dimension(H×W×D)

600mm×460mm×540mm

Product Weight

28.6kg
